The charger that runs on your sunshine.
7, 11 or 22 kW, controlled from your smartphone and fully integrated with your solar installation and your battery.
Three requirements, no compromise
Built to last, to be controlled, and to grow with your needs.
Three power levels, one charger
Pick the power: the rest of the sheet follows.
Estimated on a basis of 17 kWh per 100 km.
Ideal for : The best balance for a three-phase home.
It does not just charge. It picks the moment.
Connected to your EMS, the charger waits for your solar surplus, avoids consumption peaks and takes advantage of the cheapest hours.
Charging on solar surplus
The car charges with the energy you would have exported to the grid.
Dynamic load balancing
Power adapts live so your meter is never exceeded.
Dynamic tariffs
Charging shifts towards the most favourable hours.
Designed to be simple to live with
Everything that matters once it is on the wall.
Plug & Play, badge or app
Three ways to start a charge, whichever each user prefers.
5 m Type 2 cable
7 m optional, or a socket version to use your own cable.
Light ring
Charging status readable at a glance, even from the window.
Indoors or outdoors
IP55, from -30 to +50 degrees, wall or floor mounted.
Full specifications
Dimensions 317 x 198 x 95 mm, identical across all three power levels.
- Frequency
- 50 / 60 Hz
- Dimensions
- 317 x 198 x 95 mm
- Housing
- Polycarbonate
- Dynamic load balance
- SmartMeter (optional)
- Charging outlet
- Type 2 cable (Type 2 socket optional)
- Cable length
- 5 m (7 m optional)
- LED indicator
- Green / yellow / red / orange / white
- RFID reader
- Mifare ISO/IEC 14443A
- Start
- Plug & Play, RFID card or app
- WiFi / Bluetooth
- Yes
- RS485
- EMS interface M0
- Protocol
- OCPP 1.6J
- Residual current device
- Type A 30 mA + 6 mA DC
- Ingress protection
- IP55
- Electrical protection
- Over current, residual current, ground, surge, over and under voltage, over temperature
- Standards
- IEC 61851-1, 61851-22, 62196-2, 62955, 61851-21-2
- Certifications
- CE-LVD, CE-RED, CE-EMC, CE-RCD, CB
- Mounting
- Wall or floor
- Temperature
- -30 to +50 degrees
- Humidity
- 5 to 95 %
- Altitude
- Below 2000 m
Let us size your charger with your installation.
Our teams check your meter, your available power and your solar production before recommending a power level.
